Output Detail: Current Output: Dependent on model (derate output current 10% for 50 Hz operation)
Output Ripple: 2 mV RMS max, 3 mV peak to peak
Line Regulation: ± 0.05% for ± 10% line change
Load Regulation: ± 0.05% for 50% load change
Dynamic Response: 30 μs for 50% Load Change
Thermal Regulation: ± 0.02%/°C (maxi), ± 0.005%/°C (typical)
Voltage Input Range: 100 to 240 Vac
Current Output Range: 2.4 A
Voltage Output Range: 24 to 28 Vdc
Frequency Input Range: 47 to 63 Hz
Overcurrent Protection: 0.5 A Fuse for 100 to 120 Vac, 0.25 A Fuse for 220 to 240 Vac
Storage Temperature, Max: 185 °F
Storage Temperature, Min: -40 °F
Operating Temperature, Max: 122 °F
Operating Temperature, Min: 32 °F
