Weight: 0.25 lb
Accuracy: ± 3 %
Frequency: 10 to 1000 Hz
Materials: 316 Stainless Steel
Compliance: CE
Time Delay: 1 to 60 s
Switch Type: PNP NO (500 mA max)
Non-Linearity: < ±0.25% of span
Repeatability: < 0.5%
Switch Output: 0 to 50 mm/s
Velocity, Max: 50 mm/s
Velocity, Min: 0 mm/s
Electrical Output: 4 to 20 mA
Electrical Rating: 18 to 32 Vdc
Enclosure Ratings: IP67, NEMA Type 6
Mounting Orientation: Not Position Sensitive
Electrical Connection: M12 4 pin Female
Process Connection Size: 8 mm
Process Connection Type: Metric Male
Operating Temperature, Max: 221 °F
Operating Temperature, Min: -22 °F
