Working plate: Standard φ254mm with magnetic disc; 2.2KW
Speed of working plate: 100-1400 r/min stepless speed, Support clockwise / anticlockwise direction rotating
Four level constant speeds (stepless speed): V1=300r/min, V2=500r/min, V3=800r/min, V4=1000r/min (each speed can be set between 100-1400r/min)
Grinding head speed: 0-200r/min
Grinding head power: 0.2kw (clockwise rotating)
Grinding head lock mode: Automatic electronic lock
Sample holder: Standard φ30mm 6 pieces of samples
Automatic mode: Can be programmed speed, running time and grinding, wheel steering switch, with timing function
Samples pressure range: Center load: 0-150N (Commonly used 40-120N), Single point load: 0-90N
Pressure Loading type: Single point pneumatic pressurization + Central Pressure
Pressure adjustment: Digital voltage regulation
Timing function: 0-99 minutes
Power supply: AC220V, 50/60Hz, 2.8KW
