Sensor:
X3LC: Liquid Cooled. Frost point range -75 to 95°C, depression 100°C with 0 to 20°C secondary cooling.
Frost point range -85 to 95°C, depression 110°C with -20 to 0°C cryogenic secondary cooling.
Accuracy, All Sensors:
±0.2°C (0.36°F) dew/frost point standard
±0.1°C (0.18°F) dew/frost point optional
±0.5% of full scale pressure
Display Resolution:
0.1°C or °F
0.01 psia
0.1 ppmv below 1000 ppmv
1 ppmv above 1000 ppmv
Weight: 27 lbs. (12.5 kg)
Dimensions: 11 in. W x 11.5 in. H x 21 in. D (28 mm W x 29 mm H x 54 mm D)
Power Requirements: 90 to 230 Vac ±10%, 50 to 400Hz
Operating Temperature:
Control Unit: -10 to 60°C (15 to 140°F)
Sensors: -40 to 100°C (-40 to 212°F)
Outputs (Multiple outputs available): 4 to 20 mA, 0 to 5 Vdc, RS-232, Bluetooth and datalogging options available.
Alarms: Two Form C, SPDT alarm relays rated for 3 A at 24 Vdc, 120 Vac. Alarm mode (high or low) programmable from keyboard or RS-232. Alarm set points programmable from -99.9 to 99.9°C.
Display:
8 line LCD graphic data display, backlight
3 parameters display simultaneously
