X-ray Tube
Tube style: Sealed Tube
Tube voltage: 90KV
Tube Current: 200uA
Details Resolution: 5um
Cooling Mode: Cooling Air
Geometric Magnification Time: 125 Times
Flat Panel Detector
Pixel Size: 85um
Pixel Matrix: 1536*1536mm
Effective Imaging Area: 130*130mm
FPS Speed: 20
A/D Conversion Digits: 16bit
Sample table
Axis X: 400mm
Axis Y: 450mm
Axis Z: 300mm
Axis R: Sample table rotation plus or minus 60°
Electrical control
Control Mode: Image automatic navigation function, Point to go there to go there, The whole keyboard, Mouse operation positioning
Programming Mode: Teaching function, CNC automatic positioning
X-Ray Housing
Size: about 1100㎜* 1255㎜ *1865㎜
Weight: about 1100 kg
Power
Power Supply: AC110-230VAC, 50/60Hz
Applications
Detection of defects in PCB boards
Inspection of SMT assemblies
IC packaging defect detection.
BGA (Ball Grid Array) and CSP (Chip Scale Package) bubble welding defect detection
Semiconductor defect detection
Comprehensive defect detection for various electronic components
