X–Ray Tube
Tube Style: Sealed Tube
Tube Voltage: 160KV
Tube Current: 2.5mA
Optical Tube: 400W
Details Resolution: 0.4mm
Cooling Mode: Air Cooling
Flat Panel Detector
Effective Area: 157mm*157mm
Pixel Size: 154um
A/D Change: 16Bit
Sample Table
Axis Z: 650mm
Axis X: 400mm
Axis Y: 440mm
Axis U: ±35°tilt
Axis R: Horizontal 360° Rotation
Maximum Bearing Capacity: 30KG
Software and Image Processing Capabilities
Measuring function: The bubble crack of the test sample was determined by software.
Software processing Power: Image Inversion, Sharpening, Histogram, Binarization for better analysis of X-RAY images
Image Enhancement: Automatic Image Enhancement, Image Reverse color, Image Edge Smoothing, Texture
Software Protection Capability When the Machine is Unmanned, the X-Ray is automatically disconnected after 20 minutes, thus extending the life of the X-ray tube
Radiation safety
The machine surface: <1usv/h
Safety door automatic interlock protection function: When the X-ray is turned on, the safety door automatically locks for protection
Computer
Brand: Advantech
System: WIN10
CPU: I5
X-Ray subject
Size: Host machine：L1465mm*W1165mm*H1923mm; Operating table：L950mm*W870mm*1359mm
Weight: About 2000kg
Power
Power supply mode: AC110-230VAC,50/60Hz
Applications:
Comprehensive inspection and testing of cast components
Ensures structural integrity and quality performance
Detection of internal defects in casting materials
Verification of dimensional accuracy and consistency
