Working Distance: 0.6m – 6m
Dimensions: 164.85 x 36.00 x 40mm
Weight: 145g ±5
Power Consumption: Average Power <2.0W, Peak Power <2.5W
Baseline: 55mm
Interface: USB Type A Male
Power Supply: USB 2.0
Recommended Power: 5V 0.5A
Operating Temperature: 10°C – 40°C
Measurement Accuracy: 3mm @ 1m
Depth Image: Resolution / Frame Rate, 1280 x 1024@7fps, 1280 x 960@7fps, 640 x 480@10/15/30fps, 320 x 240@10/15/30fps, 160 x 120@10/15/30fps
Depth FOV: H58.4° V45.5° D70° ±5°
Depth Format: Y16/Y12/Y11
Color Image: Resolution / Frame Rate, 1280 x 960@7fps, 640 x 480@10/15/30fps, 320 x 240@10/15/30fps
Color FOV: H627° V49° D75.1° ±5°
Image Format: UYVY
Operating System: Windows/Linux
Application Scene: Indoor
Safety: Class 1 Laser
Camera Principle: Structured Light Monocular
Certification: RoHS 2.0/REACH/Class 1
Compatibility: myAGV Jetson Nano 2023
