Compression range: 12-54mm (1/2“-2“) Thin-wall stainless steel pipe,Plastic pipe, aluminum
plastic composite pipe, copper pipe
Note: different pipe type and material, compression range will change, should be based on the specific supporting pipe
Rated output: 32KN (Piston output)
stroke: 40mm
Oil storage: 115ml
Time consumption of single clamping: 3-4,5s (According to the diameter of the pipe fitting)
standard battery: 18V / 4.0Ah lithium battery
standard charger: AC 100V—240V 50-60HZ
Battery charging time: About 2 hour
Maintenance cycle: 30000times
Number of stuck voltage per saturated battery: About 350 times(DN20)
Weight: 3.8kg (tool with battery)
6.0kg (tool with battery and a pair of calipers)
Tool dimensions: 388x322x84mm
ACCESSORIES:
Battery: 1
2 pieces Charger: 1 piece
Mold configuration: 15,20,25,32,40,50mm
