Power Supply: DC6V alkaline dry battery (1.5V AAA×4)
Display Mode: 4-digit LCD display, backlight function, suitable for dim place
LCD Size:
LCD of detector: 35mm×21.5mm;
LCD of receiver: 47mm×28.5mm
Measurement Method: Clamp CT, integration method
Transmission Mode: 433MHz wireless transmission
Transmission Distance: 30m
Clamp Jaw Size: Φ68mm
Measurement Range: AC 0.00mA~600.0A
Current Frequency: 50Hz/60Hz automatic
Solution: 1mA
Shift Gear: 0.00mA~1200A Fully automatic shift gear
Test Accuracy:
0.00mA~100A: ±1%rdg±5dgt
100A~599A： ±1.5%rdg±5dgt
600A~1200A：±2%rdg±5dgt
Memory: 99 groups, in storage process “MEM” symbol display, “FULL” symbol flicker indicate storage full
Line Voltage: Suitable for testing insulated line below 60kV, as well as bare conductor or busbar below 35kV. (operate with insulating rod)
Data Hold: Press HOLD key to hold data in test mode, “HOLD" symbol display, press HOLD key again to cancel this function.
Data Access: "MR" symbol display, can look up all storage data
Sampling Rate: 2 times/second
Overflow Display: Exceed measure range overflow function:"OL A" symbol display
No Signal Indication: When the receiver has not received transmit signal, dynamic display "no- -"symbol
Automatic Shutdown: After 15 minutes power on, the meter shuts down automatically without any operation to reduce battery consumption
Battery Voltage: When battery voltage is lower than 4.8V, low battery voltage symbol display and remind to replace battery.
Meter Size: 135mm×215mm×60mm
Weight:
Meter: about 620g (include battery),
Receiver: about 330g(include battery),
Total weight: about 4kg(include insulating rod and battery)
Interference: No 315MHz, 433MHz same frequency signal interference
Telescoping Insulating Rod Size: About 4300mm
Insulation Strength: AC 60kV/rms (The telescopic insulating rod is completely pulled apart, between the two ends)
Structure: Anti-drip type Ⅱ
Working Temperature & Humidity: -20℃~40℃; below 80%RH
Storage Temperature & Humidity: -20℃~60℃; below 70%RH
