- Current Measurement:
+ Range: 0-1 A AC or DC
Resolution: 1 mA
Accuracy: 0.2% + 2 LSD (DC)
+ Range: 0-30 mA
Resolution: 0.001 mA
Accuracy: 0.05% + 2 LSD
- Current Sourcing:
+ Range: 0-20 mA or 4-20 mA
+ Resolution: 0.05% of span
+ Drive Capability: 24 V Compliance or 1200 Ω @ 20 mA
- Frequency: to 19.999 kHz, 0.005% + 1 LSD
- Continuity: Beeps for resistance < 100 Ω
- Voltage measurement:
+ Range: 0-1000 V AC (true-RMS) or DC
+ Resolution: 0.1 mV to 1.0 V
+ Accuracy: 0.1% Rdg + 1 LSD (VDC)
- Resistance measurement: to 40 MΩ, 0.2% + 1 LSD
Diode test: 2.0 V shows the diode voltage drop
Display current and % of span: Yes
Auto step, auto ramp: Yes
Size: 50 x 100 x 203 mm
Weight: 610 g
