Optical Magnification: 0.7X–5.0X continuously adjustable (with positioning function)
Digital Magnification: 21–150X adjustable (expandable up to 210X)
Output Interfaces: HDMI + USB 2.0 + LAN
Effective Pixels: 8.3 Megapixels
Frame Rate: 60 frames per second
Measurement Methods:
HDMI connected to monitor for measurement
USB connected to computer for measurement
LAN network port connected to computer for measurement
Measurement Accuracy: 0.002–0.005 mm (accuracy increases with magnification)
Measurement Units: mm, μm, mil, inch (4 switchable units)
Resolution: 3840 × 2160 (4K)
Storage Methods: External USB flash drive + USB/LAN software storage
Illumination: Adjustable LED light source
Display Languages: Simplified Chinese / English (switchable)
Processor:
ARM Cortex A17 Quad-core @ Max. 1.4GHz (main processor)
ARM Cortex A7 Single-core @ Max. 900MHz (video processor)
Optical Sensor Size: 1/1.7"
Pixel Size: 1.85μm × 1.85μm
Memory: 2GB DDR3
Operating System: Highpin’s proprietary measurement system based on Linux 3.1
Measurement Tools: Length, angle, arc, circle, polygon, polyline, center distance, rectangle, annotations, auto edge detection, scale bar, and more
Image Naming Methods: Automatic or manual naming
Crosshair Function: 100 horizontal and 100 vertical lines
