Test channels: 12 channels with 25V,the current is 50mA
Transducer: one analog transducer
Time:
Recording time length: 0~20.0s
Time accuracy: ±0.l% reading ± 2 LSB
Resolution: 0.1ms
Motion:
Range: 0~1000mm
Accuracy: ±1% reading ±1LSB
Resolution: 0.1mm
Velocity:
Ranges: 0.01~20.00m/s
Accuracy:±1%reading ±1LSB
Resolution: 0.01m/s
DC power:
Ranges: 5~260V
Max current: 20A
Accuracy: ±1%reading ±1LSB
Load change:≤1%
Trigger:
Voltage: 5~260V
Current: 0.1-20A
Transducer: the transducer states changes
Channels: channels states changed
Dimensions: 415mm×320mm×168mm
Weight: 8kg
Operation temperature: -10℃~50℃
Humidity: ≤80% RH
Power supply: Voltage:AC 220V±10%
Frequence:50Hz±10%
Safety:
Insulation resistance: >2MΩ
Leakage current: <3.5mA
Immunity: AC 1500V 50Hz,1min.
