PCB Size: 55*55 ~ 1200*650mm
PCB Tickness: 0.5 ~ 5.0mm
PCB Weight: ≤5.0kg
Conveyor Adjustment: Manual/automatic
Measure Type: Height,Area,Volume,Offset,Bridge,Shape
Paste Height: 0 ~ 500um
Min Measure Size: 180 ~ 180um
Min Pad Pitch: ≥100um
Measure Principle: Multi color vector boundary measurement
Height Resolution: 0.67um(theoretical value)
Camera Pixel: 530M
FOV Size: 28mm/35mm/37mm/41mm
Detection Speed: 0.45s/FOV
Program Time: 5 ~ 10min
Data Type: Gerber Data 274D/274X, Scan PCB
Barcode Scanning: Camera scanning (Option:Barcode Gun)
Power: AC220,50/60Hz,1KVA
Machine Dimension: 1700*1150*1500mm
Weight: 1600kg
