Flux Storage Tank: 1L
Flux Support: Flux Alarm, Automatic
Spray Nozzle: Germany Jet Valve (Spot and line spraying) 1set
Spray Nozzle Size: 130um (180, 210um Option)
Spray Range: 3~8mm
Spray speed: 0~20mm/s
Spray Nozzle move speed: 0~400mm/s
Spray Precision: 0.1mm
Spray Pressure: 0.05~0.1 MPa
Preheating Mode: IR Heating
Preheating Area: L500mm*W500mm
Soldering Precision: ±0.25 mm
Soldering monitoring: CCD
Solder Capacity: 12Kg
Max PCB Size: 500*500mm
Max PCB Size: 60mm
PCB Thickness: 0.5-6.0mm
PCB Weight: <20Kg
Operating System: Windows10
Power Supply: 220VAC±10%, 50/60HZ
Dimension: L1400*W2580*H1722mm
Weight: Approx:700kg
