Dimensions: 16.8 cm H x 10.2 cm L x 7.1 cm W
Weight: 170g
Performance Characteristics
Image (Pixels): 1280 pixels (H) x 1080 pixels (V)
Light Source: Illumination: 4500K LED, Aiming: 617 nm LED
Field of View: 38.5°(H) x 32.5°(V)
Roll / Pitch / Yaw: 360°, ±65°, ±60°
Print Contrast: 25% minimum reflective difference
Motion Tolerance: Up to 5 m/s
Interfaces Supported: USB, RS232
Symbology Decode Capability
1-D: UPC, EAN, Code128, Code 39, Code 93, Code 11, Matrix 2 of 5, Interleaved 2 of 5, Codabar, etc.
2-D: PDF417, MicroPDF417, Data Matrix, Maxicode, QR Code, MicroQR, Aztec, Hanxin, etc.
User Environment
Operating Temperature: 0° to 50° C
Storage Temperature: -40° to 70° C
Humidity: 5% to 95%, non-condensing
Drop/Shock Specifications: Withstands multiple 1.8m (6ft.) drops to concrete
Ambient Light Immunity: 100000 Lux
