Lowest reading: 0.01 % FS
Lowest suggested
Reading: 0.05 % FS
Control pressure: 0.5 % FS
Temperature
Operation (ambient): +5 ... +50 °C
Bakeout at flange: ≤110 °C
Storage: –20 ... +65 °C
Supply voltage: +14 ... +30 V (dc)
Power consumption: ≤1 W
Output signal (analog): 0 ... +10 V (dc)
Degree of protection: IP 30
Standards
CE conformity: EN 61000-6-2, EN 61000-6-3, EN 61010, RoHS
ETL certification: UL 61010-1, CSA 22.2 No.61010-1
Electrical connection: D-sub, 15-pin, male
Setpoint
Number of setpoints: 2 (SP1, SP2)
Relay contact: 30 V (dc) / ≤0.5 A (dc)
Hysteresis: 1 % FS
Materials exposed to vacuum: ceramics (AI2O3), stainless steel (AISI 316L)
Internal volume: ≤5.1 cm3
Weight: 285 … 342 g
