Basic
Max. Frame rate: 120 fps
Sensor Type: 1/4" CMOS
Shutter Mode: Global
Pixel Size: 5.4 μm × 5.4 μm
Mono/Color: Mono
Lens Mount: M12
Trigger Mode: Single Frame trigger/Software trigger/Free run mode
Software: SVStudio
Certifications: CE，FCC，KC
Function: DM-12&DM-14，DM4x4
Performance
Focal Length: 3.37 mm
Working Distance: 100 mm
Field of View: 110 mm × 93 mm
Max. Read Speed: 125 code/s
Max. Operating Speed: 3 m/s
Focus Control: Stationarytype
Light Source Type: WhiteLed
Depth of Field (DoF): ±20mm
Angular Accuracy: 0.1°
Displacement Accuracy: 0.1mm
Port
Connector: 1eaM12connector
Network Port: 100M Ethernet
GPIO Interface: 1 opto-isolated input，1 opto-isolated output
Communication Mode: 100MEthernet、RS485
Communication protocol: SDK，Serial，TCPServer，TCPClient
LED Indicator: 5LEDindicator，SYS、NET、Triggerand2user-definedLED
Power
Power Supply: DC24V±10%
Power Consumption: Disableillumination:<3.5W@24VDC Enableillumination:<7.5w@24VDC
Structure
Product Dimensions: 60mm×60mm×43mm(Excludedinterfaceport)
Packaging Dimensions: 164 mm × 122 mm × 91 mm
Net Weight: <225 g
Gross Weight: <350 g
Protection: IP65
Casing Material: aluminum alloy
Environment
Operating Temperature: -20℃～+50℃
Operating Humidity: 20%～95%，No condensation
Storage Temperature: -30℃～+80℃
