Rated input voltage: AC220V±15%; 50/60Hz
Rated input current: 16A
Rated power : 6KVA
Rated power (KVA): TIG: 7.3 /Stick welding: MMA: 9.2
Welding current/rated output voltage: (A/V): TIG: 200/18; Stick welding: 160/26.4
Welding current adjustment range (A): TIG: 5～200; MMA: 10～160
Load Cycle Imax (40°C) (%): TIG: 25%; MMA: 30%
No-load voltage: 56 V
Pre-flow time (s): 0.5
Output AC pulse frequency (Hz): 20-250
Cleaning with (%): 15-50
Pulse period (%): 50
Gas delay time (s): 0.5-20
Efficiency: 85%
Power factor (cosφ): 0.7
Protection class: IP21S
Insulation class: B
Arc priming type: HF
