Function: Single wire, Zipcord, Wire measuring and slitting, Cut length, Full stripping, Partial stripping, Mid-stripping, Cut depth, Wire run-out sensor, Length correction
Raw material: PVC, Teflon, Silicone, Low halogen, Fiberglass, etc.
Cutting length (L): 0.1 - 999999 mm
Cutting length accuracy: 0.002 x L
Stripping length: Front (right) side: 150 mm [partial stripping], Rear (left) side: 70 mm [partial stripping]
Middle strip: 13 sections
Production rate: 2500 pcs/h by 100mm wire length
Data library: 100 programs
Display: 4.3" color touchscreen, English / Chinese [other languages on request]
Cable feeding: 6 rollers
Compatible peripherals: Cable prefeeding unit, robot arm, cable stacker
Power supply: AC 110 - 220 V ± 10%, 50 / 60 Hz
Air supply: 0.4 - 0.7 MPa [clean and dry air]
Dimensions: Machine: L 560 x W 470 x H 370 mm, Wire straightener: 250 mm
Weight: 45 KG
• 2 core twin flat cable, zipcord
• Precise separation causes no damage to cable
• PVC, Teflon, Silicone, Low halogen, Fiber glass cables
• 4.3" color touch screen
• User-friendly English interface
• 6 rollers driven by high torque hybrid step motors
• Fully programmable, saves 100 programs
