Function: Multicore cable, Single wire, Full stripping, Partial stripping, Wire lack sensor, Length correction
Cable diameter: 14 mm
Conductor cross-sections: 0.1-16 mm² [AWG 28-6]
Cutting length (L): 0.1-999999 mm
Cutting length accuracy: 0.002 x L
Stripping length:
Leading (right) side: 400 mm [partial stripping]
Trailing (left) side: 180 mm [partial stripping]
Display: 7" color touchscreen, English / Chinese [other languages on request]
Production rate: 1200 pcs/h
Data library: 100 programs
Power supply: AC 110V-220V, 50/60 Hz
Peripherals: Cable prefeeder, robot arm, cable stacker
Air supply: 0.4-0.6 MPa (clean and dry air)
Dimensions: L 700 x W 560 x H 450 mm
Weight: 80 KG
