Function: Ribbon cable, Cable measuring, Cut length, Slitting length, Full stripping, Partial stripping, Cut depth, Length correction
Cable width: Max 20 mm
Cutting length (L): 0.1 - 999999 mm
Cutting length accuracy: 0.002 x L
Stripping length: 30 mm
Production rate: 3000 - 5000 pcs/h
Data library: 100 programs
Display: 4.3" color touchscreen, English / Chinese [other languages on request]
Cable feeding: 6 rollers
Compatible peripherals: Cable prefeeding machine, robot arm, cable collector
Power supply: AC 110 - 220 V ± 10%, 50 / 60 Hz
Air supply: 0.4 - 0.7 MPa (clean and dry air)
Dimensions: L 600 x W 570 x H 1050 mm
Weight: 68 KG
• Freestanding machine, can be moved easily
• Flat cable, ribbon cable dedicated machine
• 20mm in width, 30mm stripping length at dual-end
• 6 rollers feed system maintain feeding and pulling accuracy
• Slitting length can be adjusted simply and quickly
• 4.3" color touch screen, user-friendly interface
• Fully programmable, saves 100 programs
• Scrap jacket collector ensure neat workshop
