Function: Flat multicore cable, Wire measuring, Cut into length, Full stripping, Partial stripping, Outer jacket stripping, Inner core stripping, Wire twisting, Twist force
Raw material: PVC, Teflon, Silicone, Low halogen, Fiberglass, etc
Cable size: 2-7 mm in width
Cutting length accuracy: 0.002 x L
Cutting length (L): 0.1-999999 mm
Outer jacket stripping length:
Leading (right) side: 80 mm [partial stripping]
Trailing (left) side: 50 mm [partial stripping]
Inner core stripping length: 30 mm at dual-ends
Production rate: 1000 pcs/h by 100mm wire length
Compatible peripherals: Cable despooler and prefeeder
Air supply: 0.4-0.7 MPa (clean and dry air)
Power supply: AC 110V-220V±10%, 50/60 Hz
Dimensions: L 460 x W 780 x H 350 mm
Weight: 47 KG
