Function: Wire measuring, Cut into length, Full stripping, Partial stripping, Length correction
Raw material: PVC, Teflon, Silicone, Low halogen, Fiberglass
Conductor cross-sections: Max 70 mm²
Cable diameter: φ5 - φ18 mm
Cutting length (L): 0.1 - 999999 mm
Cutting length accuracy: 0.002 x L
Stripping length:
Front (right) side: 250 mm
Rear (left) side: 100 mm
Stripping accuracy: 0.01 mm
Production rate: 2000 pcs/h by 500mm wire length
Data library: 100 programs
Display: 7" color touchscreen, English / Chinese [Other languages on request]
Compatible peripherals: Wire prefeeder, conveyor belt
Wire feeding: Belt feeding system, 12 rollers
Power rating: 1500 W
Power supply: AC 110 - 220 V ± 10%, 50 / 60 Hz
Air supply: 0.5-0.8 MPa (clean and dry air)
Dimensions: L 720 x W 650 x H 1120 mm
Weight: 180 KG
• Heavy-duty cable up to 70mm² or 18mm diameter
• High-quality belt feeding system ensure precise feeding
• Servo motors controlled system on cutter and roller
• Imported high speed steel blade
• Quickly change guide tube
