Function: Single wire, Multicore cable, Wire measuring, Cut length, Full stripping, Partial stripping, Mid-stripping, Cut depth, Length correction, Cable rewinding (optional)
Raw material: PVC, Teflon, Silicone, Low halogen, Fiberglass, etc
Cable range: 30 mm², 15 mm diameter [Customizable]
Cutting length (L): 0.1 - 999999 mm
Cutting length accuracy: 0.002 x L
Stripping length:
Front full strip: 1-200 mm, partial strip: 1-500 mm
Rear full strip: 1-80 mm, partial strip: 1-200 mm
Production rate: 800 pcs/h
Data library: 100 programs
Winding diameter options:
WS360: 200 - 360 mm
WS680: 200 - 680 mm
WS1000: 200 - 960 mm
Display: 7" color touchscreen, English / Chinese [other languages on request]
Cable feeding: Belt feeding system, 8 rollers
Compatible peripherals: Cable prefeeding machine, robot arm, conveyor belt, cable rewinding machine
Power supply: AC 110 - 220 V ± 10%, 50 / 60 Hz
Air supply: 0.4 - 0.7 MPa (clean and dry air)
Dimensions: L 850 x W 600 x H 1300 mm
Weight: 120 KG
CE-Conformity: Complies with CE equipment guidelines relative to mechanical and electrical safety and electromagnetic compatibility.
• Compact design, freestanding model
• Cable rewinding machine is compatible
• User-friendly English touchscreen
• Transparent safety guard
