Technical parameter：
Die Specification: Double Barrel Standardφ30（Matching：φ22，φ45），Degree Centigrade
Effective depth of die: 70mm
Heating Power: 4KW
Afterburner mode: Hydraulic pressurization
System pressure: 0-300Bar
Temperature setting range: 0-60Bar
Pressure setting range: 0-200Degree Centigrade
Cooling setting range: 0-99Minutes
Mosaic time: 0-99Minutes
Suitable for mosaic material: 5In minutes（From heating to 155 degrees to cooling to 40 degrees, black mount, mount thickness within 20 mm)
Power supply: Thermoplasticity and thermoset
Total power: Voltage：220V Voltage：50HZ
Contour dimension: 4.5KW
Weight: 760X580X550
Temperature setting range: 95KG
Main functions and features:
1、The shell adopts high-end ABS one-piece forming, with novel appearance and high-end atmosphere.
2、Touch screen display control, clear and intuitive interface, easy to operate.
3、Using high-end precision hydraulic, mute technology, the whole working process noise-free.
4、The whole process is fully automatic closed-loop control, only one key to automatically complete all the mosaic process.
5、With cooling system, cooling faster, more efficient mosaic, cooling mode can choose time cooling mode, set the cooling time, when the automatic stop, can also choose temperature cooling mode, set the cooling temperature, to achieve automatic stop temperature.
6、A variety of mold specifications optional, special mold can be customized according to customer needs.
7、Manual operation can be automatic operation, according to customer needs can be arbitrary DIY operation, more flexible and convenient to use.
8、Can store more than 100 sets of MOSAIC PROCESS FORMULA, easy to quickly call, to achieve serial production。
9、According to customer needs to meet customer customized needs, all-round one-stop service.
10、Four samples can be embedded at the same time, so that the mosaic efficiency doubled in an instant.
11、Program built-in Intelligent Algorithm, can choose time mode and intelligent mode (especially suitable for first-time users).
