Application
Photoelectric integration, Anti-interference, One-button start
Compact size, saving installation space
Air self-purification system
Fully sealed structure, without fear of high temperature, high humidity environment
Specification
Wavelength: 355 nm
Average power: >15W@60kHz
Pulse duration: <20ns@60kHz
Frequency Range: 40kHz-300kHz
Spatial mode: TEM00
Beam quality: M² ≤ 1.2
Beam circularity: >90%
Beam full divergence angle: ≤2mrad
Beam diameter: 0.55 ± 0.15mm
Polarization ratio: > 100:1
Polarization orientation: horizontal
Average power stability: RMS ≤ 3% @ 24hrs
Pulse to pulse energy stability: RMS≤3%@80kHz
Operating temperature: 0~40℃
Storage temperature: -15~50℃
Cooling method: water-cooled
Supply voltage: DC 36V
Cooling Capacity Requirement: 1000W
Dimension (W x D x H): 325 × 180 × 114mm
Weight: 9.8 kg
