Capacity of work tank: 1700x1000x550mm
Work table size: 1100x600mm
Longitudinal travel(X-axis): 700mm
Cross travel(Y-axis): 550mm
Z axis travel(Z-axis+W-axis): 250+300mm
Distance between platen to table: 250~830mm
Max. Electrode weight: 250kgs
Max. Work piece weight: 2000kgs
Fluid tank capacity: 1250L
Machine outside dimensions(WxDxH): 3300x2000x2300mm
Machine weight: 3100kgs
Max. Machining current: 60A; 90A(Optional)
Max. Power input: 7KVA; 10KVA
Max. Machining rate: 400; 600 mm3/min
Min. Electrode wear ratio: 0.15%
Best surface / Ra: Ra 0.2μm
Min. D. R. O. resolution(mm): 0.005mm
