Dimensions and volumes:
Dimensions (W × L × H): 14.8 x 17.3 x 23.2 in.
Filling volume: 5 ... 7.5 l
Weight: 81.6 lbs
Pump connections: M16x1 male
Barbed fittings inner diameter: 8/12 mm
Temperature values:
Working temperature range: 0 ... +40 °C
Temperature stability: ±0.5 °C
Setting the resolution of the temperature display: 0.1 °C
Temperature display resolution: 0.1 °C
Ambient temperature: +5 ... +40 °C
Return flow temperature max.: +80 °C
Performance values:230V/50Hz (Schuko Plug - CEE 7/4 Plug Type F)
Cooling capacity: 0.5 Kw
Refrigerant: R134a
Global Warming Potential: 1430
Filling weight: 160 g
Carbon dioxide equivalent: 0.2288 t
Pump capacity flow pressure: 24 l/min
Circulation capacity pressure: 7.3 psi
Power consumption: 3A
Bath:
Bath tank: Stainless steel
Cooling:
Cooling of compressor: 1-stage Air
Electronics:
Temperature control: PID1
Temperature display: LED
Temperature setting: Keypad
