Voltage generators
Setting Range
+ 4-phase AC (L-N): 4 x 0 … 300 V
+ 2-phase AC (L-L): 2 x 0 … 600 V
Power
+ 4 x 110 VA, at 0 … 300 V
+ 2 x 220 VA, at 0 … 600 V
Accuracy: <0.07% reading + 0.03% range guaranteed at 0 … 300 V
Accuracy: <0.02% reading + 0.01% range typical at 0 … 300 V
Resolution: 1 mV
Current generators
Setting Range
+ 3-phase AC (L-N): 3 x 0 … 40 A
+ 1-phase AC (2L-N): 1 x 0 … 80 A
+ 1-phase AC (3L-N): 1 x 0 … 120 A
Power
+ 3 x 450 VA, at 0 … 40 A
+ 1 x 520 VA, at 0 … 80 A
+ 1 x 1200 VA, at 0 … 120 A (Max.)
Accuracy: <0.07% reading + 0.06% range guaranteed at 0 … 40 A
Accuracy: <0.02% reading + 0.02% range typical at 0 … 40 A
Resolution: 1 mA
Generators, general
Frequency
Range: 0 … 1000 Hz
Accuracy / drift
+ Error < 0.001 Hz at 10 … 65 Hz
+ Error < 0.01 Hz at 65 Hz … 450 Hz
+ Error < 0.02 Hz at 450 Hz … 1000 Hz
Resolution: 0.001 Hz
Phase Range: -360° … +360°
Phase Accuracy / drift: Error < 0.2°
Phase Resolution: 0.1°
Timer Range: Infinite
Timer Accuracy / drift: Error < 0.1 ms
DC generators
Voltage ranges: 0 … 300 V / 180 W
Current ranges: 0 … 20 A / 300 W
Accuracy
<0.07% reading + 0.03% range guaranteed at 0–300 V
<0.04% reading + 0.02% range typical at 0–300 V
<0.14% reading + 0.06% range guaranteed at 0–20 A
<0.05% reading + 0.02% range typical at 0–20 A
Resolution: 1 mA; 1 mV
Aux DC Supply Range: 0 … 300 V / 0.6 A
Binary inputs Number: 8 pairs
Binary inputs Compatible Voltage: 10 V … 250 V DC
Binary outputs
Number: 4 Pairs
Capacity: 250V / 3A AC/DC
Synchronization
Synchronization mode: GPS
Harmonic
Harmonic overlap times: 2 … 20 times
Power supply
Nominal input voltage: 220V AC ±20%
Power: 1000VA
Nominal frequency: 47Hz … 65Hz
Environmental conditions
Operation temperature: -5°C … 55°C
Storage temperature: -20°C … 75°C
Humidity range: 5% … 90%, non-condensing
Weight: 20 KG
Dimensions: 460(D) x 140(W) x 360(H) mm
PC connection: RJ45
