Voltage Output
Voltage Range: 4 × 0~130V RMS
Power: >65VA / Phase
Gain: 20V/V
Voltage Output Accuracy: <±0.2%
Rate Vibration of Load Change: <±0.2% (1~30VA Power output, 57.7V)
Input Impedance: >10kΩ
Frequency Range: DC-5KHz ±1dB
Harmonic Distortion Ratio: <0.2%
Input / Output Delay: <20μS (50Hz)
Step Response: <20μS
Input Signal Level: 0~7.5V RMS
Current Output
Current Range: 3 × 0~60A RMS
Power: >800VA / Phase
Gain: 8A/V
Current Output Accuracy: <±0.2%
Rate Vibration of Load Change: <±0.2% (0~2Ω, 5A)
Input Impedance: >10kΩ
Frequency Range: DC-5KHz ±1dB
Harmonic Distortion Ratio: <0.2%
Input / Output Delay: <20μS (50Hz)
Step Response: <20μS
Input Signal Level: 0~7.5V RMS
Phase
Phase Accuracy: <0.2°
Power supply
+ AC Voltage Input: 220V±10%
+ Power: 2000 VA
+ Frequency: 50Hz / 60Hz
Others
Temperature: 0℃~ 50℃
Humidity: ≤95%, no condensation
Weight: <20 kg
Dimension: 135mm×445mm×400mm, 3U 19inches
