General
Measurable Materials: Soft Magnetic Materials (Hard Ferrite, Alnico with special poles)
Measurable Quantities: Bsat, Jsat, Hsat, Br, Hr, cycle area, µrel
Measurable Shapes: Rings, bars, strips
Sample Size Ring: No physical limits (size affects max H field achievable)
Typical Accuracy Ring: Hsat, Bsat: ±1%; Hc: ±2%; Br: ±2%; µ: ±3%
Test Time: 60-120 seconds (typical)
Operating Temperature Range: 15°C ÷ 40°C
Frequency: DC
Main Cabinet
Power Supply: 220 Vac, 50/60 Hz, 16 A max absorption
Units: 16 U
Dimensions: 535 × 855 × 806 mm
Weight: 90 kg (200 lb)
Power Supply LPS
Power Output: 200 W (8V/20 A or 20V/10 A)
Resolution: 1 mV / 1 mA
Current Accuracy (Reading): ±0.15% + 5 mA
Power Supply HPS
Power Output: 1500 W (60V/25 A)
Resolution: 1.2 mV / 1.25 mA
Current Accuracy (Reading): ±0.3% ± 75 mA
