Sample Gas: Argon
Output: A ( Alarm option)
Serial Communication: Serial Interface - Profibus
Integrated Sampling System: 2 sample + zero + span
Zero Gas Free: C ( Zero gas free system)
Detector Types: Plasma emission detector for N₂
Range For N₂: 0 – 1 ppm, resolution to 10 ppb
0 – 10 ppm, resolution to 0.1 ppm
0 – 100 ppm, resolution to 1 ppm
Other range possible up to 5000 ppm configurable
Standard Features:
Manual or autoranging (user selectable)
Microprocessor controlled
Touchscreen 7" HMDI TFT display
Self diagnosis system with auto-resolve alarm
Alarm historic
Safe calibration procedure to avoid any bad calibration
Digital outputs for remote monitoring (all dry relay contacts)
System status (1 output)
Range in use (3 outputs per impurity)
Calibration in use (1 output)
Gas Connections:
Sample: 1/8" compression fittings
Vent: 1/8" compression fitting
Calibration Gas:
Zero: LDP1000 purified gas (Getter)
Span: 8.0 to 9.5 ppm N₂ (application dependant)
Sample Flow Requirements: 75 to 200 sccm
Operating Temperature: 10 °C to 45 °C
Supply: 220 V
Accuracy: Better than ± 1% full scale
Drift: < ± 1%
Response Time: T90 < 10 seconds
Operating Sample Pressure Range: 3-30 psig (for lower sample pressure requirement, an additional high purity pump is used)
Outlet Pressure: Atmospheric
Enclosure Type: 3U rackmount type
Ingress Protection: IP20 in accordance with IEC 60529
Enclosure Finish: RAL7030 powder coat
Certification: In compliance with EMC directives: IEC 61000-4-3: 2020, IEC 61000-4-6: 2013, IEC 61000-4-2: 2008, IEC 61000-4-4: 2012, IEC 61000-4-5: 2014 A1: 2017, IEC 61000-4-8: 2009, IEC 61000-4-11: 2020 for immunity & CISPR 32: 2015 A1: 2019, FCC Part 15, Subpart B: 2021, CISPR 32: 2015 A1: 2019, FCC Part 15, Subpart B: 2021 for emissions.
Weight: 29 lbs (13 kg)
