Description:
Servo control universal testing machine is easy to install, stable and reliable. The machine is a double space structure, the upper beam and the lower cross beam are the stretching space, the lower beam and the test stand are compressed space, and the test space is automatically adjusted by the sprocket and the screw driven up and down of the beam.
It has a set of servo control software to control machine operation. The test results are shown on the computer and printed easily.
Specification:
Max Test Force: 100 kn
Measure Range: 5-100 %
Relative Error Value: ±1/±0.5 %
Max Tensile Space: 480 mm
Max Compression Space: 480 mm
Piston Stroke: 150 mm
Size of Upper and Lower Platen: Φ176, Φ176 kw
Voltage: AC220/AC380V±10% 50Hz
Machine Size: 770*520*1850 mm
Net Weight: 1600 kg
