Gain: 0.5 dBi
VSWR: 2.5
Style: Microstrip
Width: 25 mm
Height: 4.5 mm
Length: 25 mm
Impedance: 50 Ohms
Cable Type: 150 mm RF1.37
Application: Mobile Applications, Drones, Robotics, IoT Applications, VR/AR Applications, Industrial Controls
Cable Length: 150 mm
Polarization: Linear
Mounting Style: PCB Mount
Electrical Type: Embedded
Frequency Range: 2.4 GHz to 2.5 GHz
Number of Bands: 1 Band
Center Frequency: 2.451 GHz
Mechanical Style: Patch
Maximum Frequency: 2.5 GHz
Minimum Frequency: 2.4 GHz
Termination Style: SMD/SMT
Protocol - Sub GHz: RFID, IoT, ISM
Antenna Connector Type: IPEX MHF
Protocol - WiFi - 802.11: 802.11, WiFi
Maximum Operating Temperature: + 105 C
Minimum Operating Temperature: - 40 C
Protocol - Bluetooth, BLE - 802.15.1: Bluetooth, BLE
Protocol - ANT, Thread, Zigbee - 802.15.4: 802.15.4 (ANT, Thread, Zigbee), 802.16
