Performance Characteristics
Azimuth:
Electrical: 0~357°
Mechanical: 0~360°
Threshold: 0.5mph (0.22m/s)
Linearity: ±1/2% of full scale
Accuracy: ±3°
Resolution: <0.1°
Damping Ratio: Standard 0.6 (magnesium tail) (meets EPA specifications)
Delay Distance: Less than 3ft (91cm)
Temperature Range: -50~65°C (-58~149°F)
Electrical Characteristics
Power Requirements: 12VDC at 10mA, 12VDC at 350mA for internal heater
Output Signal: 0~5, 0~2.5 (optional 0~1) VDC for 0~360°
Output Impedance: Ω maximum
Physical Characteristics
Weight: 1.5Ibs (0.68kg)
Finish: Clear anodized aluminum
Cable & Mounting
PN 1957: Cable Assembly; specify length in feet or meters PN 191-1
Mounting: Crossarm Assembly
