Bandwidth: 200MHz
Max. input differential voltage (DC+AC PK):
70V (20X)
700V (200X)
Noise
Full bandwidth:
20X: ≤ 20mVrms
200X: ≤ 90mVrms
CMRR
DC : >-80dB
100kHz: >-60dB
10MHz: >-30dB
100MHz: >-26dB
Delay time:
11.7ns (20X)
11.7ns (200X)
Input impedance: 6MΩ/1.67pF (differential) 3MΩ/3.3pF (each input to ground)
Output impedance: 1MΩ
Accuracy (Typical): ±2% (Customizable 1% accuracy)
Power supply: DC 5V
Overload indication: LED flash, buzzer
Dimension: L：13.5cm W：5cm H：2.5cm
Input cable length: 31cm
Output cable length: 100cm
Temperature
Working：0℃ ~ 40℃
Non-working：-30℃ ~ 70℃
Humidity
Working： 5 ~ 85% RH ( 0℃ ~ 40℃ )
Non-working： 5% ~ 85% RH ( ≤ 40 ℃ )；5% ~ 45% RH (40 ℃ ~70 ℃ )
Standard Accessories:
Main unit*1
Extendable Hook Pliers*1 Pair
Alligator Clips*1 Pair
Input Extension Cables*1 Pair
Power adapter*1
BNC Output Lin*1
USB Line*1
Quick Guide*1
