Digital/Analog: Digital
Inch-Metric
Range: 1"/25.4 mm
Digital step: 0.0005"/0.01 mm
Max. Permissible Error E MPE (Total Range): ±0.001"/0.02 mm
H MPE (Hysteresis): 0.001"/0.02 mm
R MPE (Repeatability): 0.0005"/0.01 mm
Measuring force MPL: ≤1.8 N
Protection: IP42
Type: EN ISO Standard
Mass: 190 g
Display: LCD, character height 11 mm, 330° rotatable
Max. response speed: Unlimited
Measurement frequency (MAX/MIN/RANGE): 50 times/s
Alarm: Low voltage, setting errors, sensor error, display overflow a.s.o.
Stem ∅: 8 mm
Contact point: Carbide ball, thread: M2.5x0.45
Power supply: 1 battery CR2032
Battery life: Approx. 2700 hours (continuous use)
Digital Scale: Electrostatic capacitance type absolute linear encoder
ON/OFF: Yes
ABS / INC (INC ZERO): Yes
Function lock: Yes
GO/±NG judgement: Yes
DATA/HOLD: Yes
Auto Power OFF setting: Yes
Counting direction switchable: Yes
Customizing keys: Yes
Calibration warning function: Yes
Low voltage alarm: Yes
Digital step switchable: No
Digimatic data output: Yes
Digimatic S1 Bidirectional interface: Yes
Analog bar resolution switchable: Yes
Inch/Metric switchable: Yes
