Frequency: 13.56MHz ±0.005%
Dynamic Power Range: 10 - 1250 W
Power Output: 1.25 kW
Load Impedance Range: Unlimited
RF Stability/Spurious Output: Unconditionally stable for any load within operational limits < -45dBc
Harmonic Output & Distortion: < -40dBc
Regulation Tolerance: >125 W: ±1.5% SP, <125 W: ± 3.0 W
Input AC Power: 200/208 VAC, 3/PE~ (3W+G) 14 A/PHASE, 380/400 VAC, 3/PE~ (3W+G) 7.5 A/PHASE
RF Connector: Type N
Interface: Standard: RS-232 Subminiature Type-D 9-pin digital, optional custom interface cards available.
Rack Mountins: EIA (Standard) 19-inch adapters supplied
Cooling System: Water flow at 2.0 Gal./Min. (7.6 LPM) minimum at 5 - 35°C. Connections provided to accept 3/8 inch male (NPT) pipe thread
Dimensions: Rack Mount: 3.5 x 19 x 20.0 inches (89 x 483 x 508 mm) (HxWxD)
Weight: 32.5 lbs. (14.8 kg)
