Output: IEPE
Sensitivity: 100 mV/g
Measuring range: ±60 g
Linear frequency range (±3 dB): 0.13 .. 11000 Hz
Protection grade: IP67
Connector: Binder 713 (M12), radial
Weight: 106 g
Option:
Connection accessories:
• 080G/W: 4-pin plug Binder 713 angled (W) or straight (G) with screw terminals for cables with Ø 4..6 mm; IP67
• 085-B713G-PIG-5/085-B713W-PIG-5: shielded cable; 5 m; PUR jacket Ø 6 mm; with angled (W) or straight (G) plug Binder 713 (IP67) and pigtail
• 085-B713G-BNC-5/085-B713W-BNC-5: shielded cable; 5 m; PUR jacket Ø 6 mm; with angled (W) or straight (G) plug Binder 713 (IP67) and BNC plug
Mounting accessories:
• 043: Mounting stud M8
• 229: Stainless steel adhesive pad M8
• 208: Magnetic base M8
• 230: Triaxial mounting cube M8 (not for KS81)
Datasheet
