Maximum test force: 300kN
Horizontal host structure: horizontal four-column host structure
Specimen size: steel strand diameter 12.7mm 15.24mm, length ≥ 1.2m
Effective load measurement range: 10 ~ 300kN
Load measurement accuracy: better than ±1% of the indicating value
Test force error: ≤±1.0%
Load cell creep: 30 minutes ≤ 0.02%
Resolution of temperature sensor: 0.1℃
Temperature sensor accuracy: ±0.3℃
Displacement measurement accuracy: better than ±0.5% of the indicating value
Deformation measurement accuracy: ±0.001mm
Resolution of control system: no less than 500,000 yards
Noise: ≤35dB
Loading speed: 100～5000N/S, set arbitrarily
Effective stroke: 200mm
Power supply: voltage 380V±10%, 220V±10%, 50HZ; power 2.0kW
