Decode Capability: 1D, 2D
Interface: RS-232, USB, TTL-232
Illumination: White LED
Dimension: 61.5×65.5×31.9mm
Weight: 33g
Image Sensor: 640 * 480 CMOS
Illumination: White LED
Symbologies
2D: PDF 417, QR Code, Micro QR, Data Matrix, Aztec, Maxicode, Chinese Sensible Code, GM Code, Micro PDF417 Code, Code One
1D: EAN-8, EAN-13, UPC-E, UPC-A, Code 128, UCC/EAN128, I2Of5, ITF-14, ITF-6, Matrix 25, CodaBar, Code 39, Code 93, ISSN, ISBN, Industrial 25, Standard 25, Plessey, Code11, MSIPlessey, UCC/EAN Composite, GS1 Databar, Code 49, Code 16K
Resolution: ≥5mil
Typical Depth of Field
EAN-13: 25mm-110mm (13mil)
QR Code: 0mm-90mm (15mil)
PDF417: 35mm-45mm (6.7mil)
Data Matrix: 35mm-50mm (10mil)
Min. Symbol Contrast: 30%
Scan Angle: Roll: 360°, Pitch: ±40°, Skew: ±45°
Field of View: Horizontal 68°, Vertical 51°, Diagonal 84.8°
