Image Sensor: 640 * 480 CMOS
Light Source: White LED
Barcodes: 1D, 2D
Resolution: >5mil
Scan Angle: Pitch: ±50°; Roll: 360; Skew: ±45°
Field of View: Horizontal 69.5°, Vertical 54.8°
Scan Window: 82mm × 64mm
Minimum Symbol Contrast: 30%
Screen Brightness: ≥15%
Connectivity: USB
Operating Voltage: 5VDC±5%
Rated Power Consumption: 837.3mW
Current@5VDC: 118.4mA (typical), 174.5mA (max)
Dimensions (L×W×H): 100.3(W)×120.3(D)×102.8(H)mm
Weight: 296g
Notification: Beeper, LED
Operating Temperature: -20°C to 60°C (-4°F to 140°F)
Storage Temperature: -40°C to 70°C (-40°F to 158°F)
Humidity: 5%~95% (non-condensing)
ESD: ±8 KV (air discharge); ±4 KV (direct discharge)
Protection Standard: IP42
