Image Sensor: 1280×800 (megapixel) CMOS
Light Source: Diffused: Blue LED ring
Barcodes:
1D: EAN-13, EAN-8, UPC-A, UPC-E, ISSN, ISBN, Code 128, Code 39, Codabar, UCC/EAN 128, AIM128, Interleaved 2 of 5, ITF-14, ITF-6, Standard 2 of 5, Matrix 2 of 5, COOP 25, Industrial 2 of 5, Plessey, MSI Plessey, Code 11, Code 93, ISBT128, Deutsche14, Deutsche12.
2D: QR Code, Data Matrix, PDF 417.
Resolution: ≥3mil
Depth of Field: Data Matrix: 0-20mm (6.7mil). Data Matrix: 0-25mm (10mil). QR Code: 0-30mm (10mil)
Scan Angle: Pitch: ±45°, Roll: 360°, Skew: ±45°
Field of View: Horizontal 32.7°, Vertical 20.7°
Minimum Symbol Contrast: 25%
Connectivity: USB
Operating Voltage: 5VDC±5%
Rated Power Consumption: 1275mW (typical)
Current@5VDC: 230mA (typical), 255mA (max)
Dimensions (L×W×H): Height: 100mm, Diameter: 65mm
Weight: 332g
Notification: Beeper, LED
Operating Temperature: -20°C to 60°C (-4°F to 140°F)
Storage Temperature: -40°C to 70°C (-40°F to 158°F)
Humidity: 5%~95% (non-condensing)
ESD: ±8 KV (direct discharge); ±15 KV (air discharge)
Drop Resistance: 1.2m/3.94ft.
Protection Standard: IP64
