Width: 5 mm
Height: 1.6 mm
Length: 10 mm
Shutdown: No Shutdown
Technology: Bipolar
Supply Type: Dual
Amplifier Type: General Purpose Amplifier
Mounting Style: SMD/SMT
SR - Slew Rate: 13 V/us
Voltage Gain dB: 106 dB
Number of Channels: 4 Channel
Dual Supply Voltage: +/- 5 V, +/- 9 V, +/- 12 V, +/- 15 V
Supply Voltage - Max: +/- 18 V
Supply Voltage - Min: +/- 4 V
Pd - Power Dissipation: 700 mW
Ib - Input Bias Current: 200 pA
Operating Supply Current: 10 mA
Operating Supply Voltage: +/- 4 V to +/- 18 V
Vos - Input Offset Voltage: 10 mV
Maximum Dual Supply Voltage: +/- 18 V
Minimum Dual Supply Voltage: +/- 4 V
GBP - Gain Bandwidth Product: 3 MHz
Maximum Operating Temperature: + 75 C
Minimum Operating Temperature: - 20 C
CMRR - Common Mode Rejection Ratio: 70 dB
