Core: ARM Cortex M4
Width: 6 mm
Height: 0.85 mm
Length: 6 mm
Technology: Si
Sensitivity: - 97 dBm
Output Power: 4 dBm
Data RAM Size: 24 kB
Data RAM Type: RAM
ADC Resolution: 12 bit
Data Bus Width: 32 bit
Interface Type: SPI
Mounting Style: SMD/SMT
Number of I/Os: 32 I/O
Number of Timers: 3 Timer
Maximum Data Rate: 2 Mbps
Operating Frequency: 2.36 GHz to 2.5 GHz
Program Memory Size: 192 kB
Program Memory Type: Flash
Supply Voltage - Max: 3.6 V
Supply Voltage - Min: 1.7 V
Number of ADC Channels: 8 Channel
Maximum Clock Frequency: 64 MHz
Operating Supply Voltage: 1.7 V to 3.6 V
Supply Current Receiving: 11.2 mA
Operating Temperature Range: - 40 C to + 85 C
Supply Current Transmitting: 15.4 mA
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
