Motion System
Type: Closed-loop servo motors with encoders
X-Travel: 500 mm
Y-Travel: 525 mm
Z-Travel: 100 mm maximum
Encoder Resolution: 0.005 mm. (0.0002 in.)
X-Y Velocity: 1.0 m/s (39.4 in./s)
X-Y Acceleration: 1 g peak with S-curve jerk control
Z-Axis Velocity: 250 mm/s (10 in/s)
X-Y Repeatability: 0.025 mm. (0.001 in.), 3 sigma
Z-Axis Repeatability: 0.025 mm. (0.001 in.), 3 sigma
X-Y Resolution: 0.010 mm. (0.0004 in.), 3 sigma
Z-Axis Resolution: 0.025 mm. (0.001 in.), 3 sigma
Positional Accuracy: 0.075 mm. (0.003 in.), 3 sigma
Conveyor
In-Line: Standard chain conveyor
Motor Driven: Width Adjustment 35 to 475 mm (1.4 to 18.7 in.)
Maximum Clearance: 100 mm (4 in.) above and below PCB
Maximum Pallet/PCB Weight: Standard: 5 kg (11 lbs.)
Adjustable Tooling Rails
Width Adjustment: 35 to 475 mm (1.4 to 18.7 in.)
Maximum Clearance: 100 mm (4 in.) above and below PCB
Maximum Pallet/PCB: Weight Standard: 5 kg (11 lbs.)
Tooling Plate is Available: Aluminum; 5 mm (0.2 in.) thickness; 508 x 508 mm (20 x 20 in.)
Aluminum Extrusion Profile: The rail spacing is adjusted by moving the back rail
Computer: Laptop or IPC
Software: EasyCoat® software: Windows® 10 operating system
Fluid Delivery Methods
Precise Non-Atomized Conformal Coating: Select Coat® SC-280 Film Coater (circulating and non-circulating)
Versatile, Atomized Spray Coating:
Select Coat® SC-300 Multi-Mode applicator
Select Coat® SC-350 Select Spray applicator
Highly Selective, Precision Jet Coating: SC-400 PreciseCoat® conformal coating jet
Versatile Valves: DV-0X Series
