UCI U2 probe loads: 1kg (10N), 5kg (50N), 10kg (98N)
Measurement error: <4% (HV5, HV 10)
Scales: HV, HRA, HRB, HRC, HRD, HRE, HRF, HRG, HRH, HRK, HB, HBS, HBW, HK, HR 15-N, HR 30-N, HR 45-N, HR 15-T, HR 30-T, HR 45-T, HR-15W, HS, HLD, Rm, Knoop, Tensile strength Rm/MPa
Materials:
+ Pre-calibrated for Non-Austenitic Steel, Nickel and High-Nickel Alloys,
+ Cartridge Brass, Copper No. 102 to 142 Inclusive, Alloyed White Irons,
+ Wrought Aluminum Products, Steel (unalloyed, low alloy and cast),
+ Steel (quenched tempered condition), Steel (untreated, soft annealed or normalized conditions), Steel (quenched condition),
+ Cold working steels, High speed steels, X110MoCo9.8,
+ Hardmetals, Aluminium and its alloys *additional custom scales and materials for calibration
Measuring direction : Any direction 360°
Display: 5.5" touch screen, 720x1280, IPS LTPS
Camera: 13MP
Connectivity: WWAN (2G/3G/4G, VoLTE), WLAN/Wi-Fi, Bluetooth, GPS, USB Type-C
CPU: Octa-core ARM@Cortex -A53 MPCore 2.0 GHz
Body: Explosion-proof industrial design, IP65 (IP67 optional) dust and water protection (IEC 60529)
Memory: 4GB RAM + 64GB ROM Memory
Languages: English, Ukrainian, Russian *additional languages available by request.
Power supply / Charging: Built-in battery 5100mA/h (Lithium Polymer) / USB 5V/2А
Batteries life: 12 h
Operating environment: Temperature: -20°C ~ 50°C, Humidity: <95% R.H. at 35°С
Dimensions and weight of tester: 160х84x17.5 mm / 0.3 kg
