Core: ARM Cortex A35, ARM Cortex M4F
Application: Industrial
I/O Voltage: 1.8 V, 2.5 V, 3.3 V
Memory Type: DDR3L, LPDDR4, SRAM
Data RAM Size: 256 kB, 512 kB
Data Bus Width: 64 bit
Interface Type: ADC, CAN, CAN FD, Ethernet, I2C, MIPI-CSI, MIPI-DSI, QSPI, PCIe, PWM, SAI, SPDIF, SPI, UART, USB 2.0 OTG, USB 3.0 OTG, Video
Mounting Style: SMD/SMT
Number of Cores: 5 Core
Watchdog Timers: Watchdog Timer
Instruction Type: Fixed/Floating Point
Moisture Sensitive: Yes
L1 Cache Data Memory: 16 kB, 4 x 32 kB
Maximum Clock Frequency: 264 MHz, 1.2 GHz
Operating Supply Voltage: 1 V
L1 Cache Instruction Memory: 16 kB, 4 x 32 kB
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 40 C
L2 Cache Instruction / Data Memory: 512 kB
