Width: 305 mm
Height: 152 mm
Length: 280 mm
Weight: 7.2 kg
Accuracy: ± 0.5 °C
Frequency: 50/60 Hz
Stability: ±0.1°C
Target Size: 63.5
Control Mode: PID Control
Display Type: LED
Warm Up Time: 12 min
Accuracy Note: ±0.5°C, ±0.25% rdg (±0.9°F, ±0.25% rdg)
Data Interface: RS232
Supply Voltage: 115 Vac
Cavity Emissivity: 0.95
Power Consumption: 75 W
Warm-Up Time Note: 12 min from ambient to 204°C (400°F)
Additional Features 1: Portable
Installation Category: II
Internal Sensing Element: Platinum RTD, class A, alpha = 0.00385
Process Temperature, Max: 215 °C
Process Temperature, Min: 10 °C
Operating Temperature, Max: 45 °C
Operating Temperature, Min: 5 °C
Calibration Reference Sensor: Platinum RTD, class A, alpha = 0.00385
