Width: 84 mm
Height: 28 mm
Keypad: 12 Switches
Length: 193 mm
Weight: 362.9 g
Auto Off: 20 min
Compliance: CE, Mil-PRF-28800F Class 2, REACH, RoHS 2
Sanitation: NSF, ANSI/3-1 14159-2
Statistics: Average, Maximum, Minimum, Range, Standard Deviation
Weight Note: 362.9g (including batteries)
Battery life: 500 hr
Display Type: Backlit LCD
EMC Standard: Class 2, EN 61326, MIL-PRF-28800F
ESD Standard: IEC 61326 Criterion B
Reading Rate: 3/sec
Auto Off Note: 20 minute no key pressed Auto Off. Feature can be disabled
Input Current: ± 50 nA
Supply Voltage: 4.5 Vdc
Millivolt Range: -15 to 85 mV
Resolution Note: 0.01°C UP TO 999.99°C AND 0.1°C ≥ 1000°C
Resolution, Max: 999.99 °C
Resolution, Min: 0.01 °C
Display Backlight: Four (4) LED Backlight with 30-second timeout
Display Type Note: 5-DIGIT AUTO-RESOLUTION (0.1/0.01) WITH BACKLIGHT AND FUNCTION ANNUNCIATORS Two (2) rows of Five (5) digit LCD with separate minus sign, decimal indicators, with offset, thermocouple types KJTEBNRSGCDPLU, battery, source, read, temperature units, voltage units, percent, trend, PRST (0-19), MIN, MAX, AVG, RNG, STDEV, Transfer, symbols: Fast Ramp, Slow Ramp, Step, Bluetooth
Electrical Safety: IEC-61010
Reading Rate Note: 3/sec. for Readings and TREND indicators
Thermocouple Type: J, K, T, E, R, S, B, C, N, L, G, U, D, P
Battery Indication: 4 stage battery charge indication
Display Resolution: 0.01°
Weight (CJC error): 12.8 oz (including batteries)
Cold Junction Error: ± 0.15 °C
Common Mode Voltage: 42 V
Low Resistance Load: Less than 5µV change in output with a 100KΩ resistance
Additional Features 1: Read and Source Signals
Electrical Connection: Miniature Female Thermocouple Connector
Operating Environment: Altitude: 0 to 4600 m ; 0 to 15,092 ft(CJC Error) Vibration: Random 10 – 500 Hz; 0.03 g2/Hz(CJC Error) Shock: 30g Half Sine Drop: 4 Drops from 1 m to Concrete
Dimensions (CJC error): 7.6 L x 3.3 W x 1.1 H in
Relative Humidity Note: <10 °C (50 °F): Non-condensing 10 to 30 °C (50 to 86 °F): 5 to 95% RH 30 to 40 °C (86 to 104 °F): 5 to 85% RH 40°C to 55°C (104 to 131 °F): 5 to 60% RH
Relative Humidity, Max: 0.95
Relative Humidity, Min: 5%
Display Measuring Units: °C, °F, mV
Internal Preset Storage: 20 user defined presets available
Temperature Coefficient: For specification variances due to ambient operating temperature, see the Expanded Instrument Uncertainty charts in Appendix B of this manual. For ambient operating temperatures not shown in Appendix B, accuracies shall be interpolated linearly.
Common Mode Voltage Note: 42 V peak to earth; 1 V p-p between T1 and T2
Probe Offset Uncertainty: Resolution 0.1 °C/°F
Storage Temperature Note: Storage Temperature(CJC error): -59.8 to 159.8°F
Storage Temperature, Max: 71 °C
Storage Temperature, Min: -51 °C
Operating Temperature Note: Operating Temperature(CJC error): -4 to 131°F
Operating Temperature, Max: 55 °C
Operating Temperature, Min: -20 °C
Display Resolution (CJC error): 0.1°
Power Cycle Configuration Retention: Instrument retains: Sensor Type, Temperature Unit Offset Values, Presets, Statistics, Open Lead detection status, 0%/100% span settings, and operating mode
Common Mode Voltage (CJC error), Max: 1 V
